Product Description
AUTO ROD CONTROLS, Switch Panel, Pro Street, Bar Mount, 8 x 2-3/8 x 2 in, 7 Rocker Switches, Fused, Aluminum, Black, Kit
1) Starter Switch
Recessed to prevent accidental striking, It is mounted
nearest the driver and next to the ignition switch for ease
of operation.
2) Ignition Switch
This switch interlocks to the fuel pump controls shutting
the pumps off when ignition is killed. The switch is lighted
red when on to aid in night racing.
3) Fuel pump switches
Off in the center position, on - in the up position. They
are safety interlocked with the ignition switch. The down
position is a spring return marked "test" which bypasses
the ignition interlock for the purposes of filling the
carburetors, setting pressure regulators and float levels
or individually checking pump outputs. Dual switching
also allows the use of only one pump in the non race
running conditions saving the batteries. The 2nd switch
can also be used for any other function.
4) Cooling Switch
Designed to operate an electric water pump in the "low
cool" position and both an electric water pump and
electric radiator fan in the high position.
5) Lamps
To allow the gauges and/or headlights to be lighted only
when needed extending the bulb life. Units have a three
position lamp switch: off - down, Middle gauges only and
up for gauges and headlights
Both in dash and overhead units hinge out for easy
access to fuses. It also contains two spare fuses
